The Mazak FJV series delivers high-precision and high-productivity within a robust double-column vertical machining center. Enhanced with intelligent functions and solid construction, these machines are engineered to perform over over extended operational periods with consistent accuracy. In addition, Mazak engineers eliminated the spindle overhang, commonly found in C-frame designs, for better machining stability. As a result, it’s ideal for industries that demand meticulous accuracy.
| Model | FJV 100/120, FJV 100/160 |
|---|---|
| Tool shank | 50 |
| Table size | 118.11" × 78.74", 157.48" × 78.74" |
| Y Axis Stroke | 96.46" |
| X Axis Stroke | 125.98", 165.35" |
| Z Axis Stroke | 25.98" |
$1.00
The FJV-100’s double-column vertical machining construction provides superior rigidity to minimize deflection and vibration during aggressive cuts. This stable platform ensures repeatable accuracy over long production runs with challenging materials. In addition, this machine has a wide work envelope and excellent visibility, which enables machinists to take on complex part geometries with tight tolerances.
With a high-speed spindle and rapid traverse rates, the FJV-100 delivers exceptional cutting performance across a wide range of materials. In addition, the CNC milling machine supports both prototype work and high-volume production, enabling shops to maintain lean operations and shorten cycle times. Its ability to maintain part quality while running at higher speeds also improves throughput and lowers overall cost per part.
Engineered as part of Mazak’s trusted FJV lineup, this scalable CNC machining solution meets modern production challenges. From aerospace structures to medical components, it supports a variety of industries. Its combination of precision, reliability, and efficiency makes it a cornerstone machine for modern, competitive manufacturing facilities.
Compare to other Mazak Vertical Machines for Sale
| Model | FJV 100/120, FJV 100/160 |
|---|---|
| Tool shank | 50 |
| Table size | 118.11" × 78.74", 157.48" × 78.74" |
| Y Axis Stroke | 96.46" |
| X Axis Stroke | 125.98", 165.35" |
| Z Axis Stroke | 25.98" |
| Table | Table size | 118.11″ × 78.74″ |
|---|---|---|
| Distance between columns | 98.43″ | |
| Max. loading weight(equal distribution) | 11023 lbs | |
| Spindle | Tool shank | CAT No.50 |
| Max. spindle speed | 10000 rpm | |
| Max. torque (40% ED) | 258 ft-lbs | |
| Max. torque (cont. rating) | 176 ft-lbs | |
| Spindle motor (40% ED) | 37 kW (50 HP) | |
| Spindle motor (cont. rating) | 30 kW (40 HP) | |
| Automatic tool changer | Tool storage capacity | 60 |
| Max. tool diameter | Φ4.92″ | |
| Max. tool diameter (without adjacent) | Φ8.27″ | |
| Max. tool length (from gauge line) | 14.96″ | |
| Max. tool weight | 44 lbs | |
| Travel | X-axis | 125.98″ |
| Y-axis | 96.46″ | |
| Z-axis | 25.98″ | |
| Distance from table top face to spindle end | 6.3″ to 32.28″ | |
| Rapid traverse rate | X-axis | 1181 IPM |
| Y-axis | 1575 IPM | |
| Z-axis | 1181 IPM | |
| Machine dimensions | Width x Length (MAZATROL SmoothG) | 205.41″ × 368.98″ |
| Height | 141.73″ | |
| Machine weight | 98325 lbs |
| Table | Table size | 157.48″ × 78.74″ |
|---|---|---|
| Distance between columns | 98.43″ | |
| Max. loading weight(equal distribution) | 22046 lbs | |
| Spindle | Tool shank | CAT No.50 |
| Max. spindle speed | 10000 rpm | |
| Max. torque (40% ED) | 258 ft-lbs | |
| Max. torque (cont. rating) | 176 ft-lbs | |
| Spindle motor (40% ED) | 37 kW (50 HP) | |
| Spindle motor (cont. rating) | 30 kW (40 HP) | |
| Automatic tool changer | Tool storage capacity | 60 |
| Max. tool diameter | Φ4.92″ | |
| Max. tool diameter (without adjacent) | Φ8.27″ | |
| Max. tool length (from gauge line) | 14.96″ | |
| Max. tool weight | 44 lbs | |
| Travel | X-axis | 165.35″ |
| Y-axis | 96.46″ | |
| Z-axis | 25.98″ | |
| Distance from table top face to spindle end | 6.3″ to 32.28″ | |
| Rapid traverse rate | X-axis | 1181 IPM |
| Y-axis | 1575 IPM | |
| Z-axis | 1181 IPM | |
| Machine dimensions | Width x Length (MAZATROL SmoothG) | 205.41″ × 474.17″ |
| Height | 141.73″ | |
| Machine weight | 101190 lbs |
